Power Connectors

Power Connectors

Compare (0/5)

9 products

Contact for Accommodation ME175 or MN180 Series

Contact for Accommodation ME175 or MN180 Series

Contacts designed for use in ME175 and MN180 series connectors
Compatible with large gauge cables
Models such as ME1382 (for 50 mm² / 1/0 AWG) and ME1383 (for 35 mm² / 2 AWG)
Made of copper alloy with silver plating
Technical specifications See all models
Contact for Accommodation Series ME350

Contact for Accommodation Series ME350

High-retention cylindrical contacts
For large gauge cables, from 50 mm² (#1/0 AWG) to 120 mm² (#4/0 AWG)
Copper alloy materials with silver finish
Technical specifications See all models
Modular Unipolar Housing MN75 Series

Modular Unipolar Housing MN75 Series

Single-pole connector with integrated spring retention system
Accepts contacts for cables from 6 mm² (#10 AWG) to 16 mm² (#6 AWG)
Features polarized housing and alignment pin system
Materials are UL94V-0 polycarbonate and stainless steel springs
Technical specifications See all models
Contact for MN15/45 Series Housing

Contact for MN15/45 Series Housing

Closed barrel type contact
Supports up to 30A, suitable for 1.0 to 2.5 mm² wires
Copper alloy materials with silver finish
Technical specifications See all models
MN15/45 Series Modular Single-Pole Housing

MN15/45 Series Modular Single-Pole Housing

Unipolar connector with integrated spring retention system
Accepts contacts for cables from 1 mm² (#17 AWG) to 6 mm² (#10 AWG)
Features polarized mating and alignment pin system
Materials: UL94V-0 polycarbonate and stainless steel springs
Technical specifications See all models
Contact for Housing for ME50 or MN75 Series

Contact for Housing for ME50 or MN75 Series

Contacts designed for use in ME50 and MN75 series connectors
Copper alloy materials with silver finish
Technical specifications See all models
Contact for ME175 or MN180 Series Housing

Contact for ME175 or MN180 Series Housing

Contacts designed for use in ME175 and MN180 series connectors
Compatible with large gauge cables
Copper alloy materials with silver finish
Technical specifications See all models
ME50 Series Bipolar Housing

ME50 Series Bipolar Housing

Two-pole connector with integrated spring retention system
Supports up to 600V
Accepts cables from 4 mm² (#12 AWG) to 16 mm² (#6 AWG)
Materials: UL94V-0 polycarbonate and stainless steel springs
Technical specifications See all models
ME175 Series Bipolar Housing

ME175 Series Bipolar Housing

Bipolar connector with integrated spring retention system
Supports up to 175A and 600V
Accepts cables from 25 mm² (#4 AWG) to 50 mm² (#1/0 AWG)
Materials in UL94V-0 polycarbonate and stainless steel springs
Technical specifications See all models
