Terminal for MCF Cable

CÓD: MCFTF

Description

Subminiature modular connector terminal in tin-plated brass, ensuring a secure and reliable connection. Available in male and female versions for receptacles, plugs, male for PCB (180° and 90°) and 90° smooth, from 2 to 24 ways. Supports up to 5A and 250 VAC/VDC, meeting various electronic and industrial applications.

  • Subminiature modular connector terminal
  • Compatible with 24 to 20 AWG cables, 2 to 24 contacts
  • Male and female versions for receptacles, plugs, male for PCB (180° and 90°), and 90° smooth
  • Capacity up to 5A and 250 VAC/VDC

Select the options below

General specifications
Contact rating5A VAC/VDC
Max. operating voltage250VAC
Max. initial contact resistance20mΩ
Insulation resistance1000MΩ min. (500VDC)
Dielectric strength1500VAC (1 minuto)
Operating temperature-25 ~ +85°C
Insulator materialMCFAF = PA66 UL94V-2
MCFAM = PA66 UL94V-0
MCFPQ = PA66 UL94V-0
MCFPL = PBT UL94V-0
MCFPT = PBT UL94V-0
PCB connector terminal materialTin-plated brass
Crimp terminal materialPhosphor bronze, tin-plated
Applicable wire gauge for crimp terminal24 ~ 20 AWG (0.20mm² ~ 0.50mm²)
