SE Sockets for IC
CÓD: SEE-06
Description
Description
The IC socket is designed for high-precision mounting on printed circuit boards. Available in various contact configurations, it adapts to different integrated circuit packages. With low contact resistance and excellent insulation, it ensures reliable performance in electronic applications.
- Available in versions from 6 to 48 pins
- Maximum current of 1A and voltage up to 150V
- Insulator made of PBT with 30% fiberglass UL94V-0
Select the options below
Code list
Code list
| Code | Description |
|---|---|
| SEE-06 | 6-Way / 7.62mm |
| SEE-08 | 8-Way / 7.62mm |
| SEE-14 | 14-Way / 7.62mm |
| SEE-16 | 16-Way / 7.62mm |
| SEE-18 | 18-Way / 7.62mm |
| SEE-20 | 20-Way / 7.62mm |
| SEE-28 | 28-Way / 7.62mm |
| SEL-24 | 24-Way / 15.24mm |
| SEL-28 | 28-Way / 15.24mm |
| SEL-32 | 32-Way / 15.24mm |
| SEL-40 | 40-Way / 15.24mm |
General specifications
General specifications
| Maximum current | 1A |
| Maximum voltage | 150VAC/VDC |
| Max. initial contact resistance | 20mΩ |
| Min. insulation resistance | 1000MΩ |
| Dielectric strength | 1000VAC (1 minuto) |
| Operating temperature | -55°C ~ 125°C |
| Insulator material | PBT+30% of fiber of glass |
| Contact and terminal material | Tin-plated phosphor bronze |
| Force of insertion (per contact) | 350g max. |
| Force of extraction (per contact) | 80g min. |
