SF01 Air Flow Sensor
CÓD: SF01
Description
Description
The SF01 is an airflow sensor designed to indicate the presence of ventilation in industrial systems. Its operation ensures greater safety and reliability in applications with fans and cooling modules. It has an IP20 protection rating and a normally open contact, which closes when there is airflow.
- Available for fans from 80 mm to 200 mm
- Include reusable synthetic fiber filter
- IP54/IP55 protection rating
- Plastic body compliant with RoHS standards
General specifications
General specifications
| Normalmente aberto (IN THE) | Contact fechado when the ar está fluindo |
| Máx. switching of voltage | 60VDC / 60VDC |
| Máx. current of switching | CC 170mA / DC 170mA |
| Máx. rating of switching | 10W (carga resistiva) |
| Operating temperature | -20 ~ 50°C / -4 ~ 122°F |
| Storage temperature | -20 ~ 80°C / -4 ~ 176°F |
| Degree of protection | IP20 |
| Protection against electric shock | Class II - double insulation |
