Components

IC Sockets

CÓD: STE-06

Description

The ST series IC socket is designed for electronic applications that require high precision and durability. Available in various contact configurations, it adapts to different integrated circuit packages. With low contact resistance and excellent insulation, it ensures reliable performance in technical environments.

  • Available in 6 to 40-pin versions
  • Maximum current of 1A and voltage up to 150V
  • PBT insulator with 30% fiberglass UL94V-0

Select the options below

General specifications
Maximum current1A
Maximum voltage150VAC/VDC
Max. initial contact resistance20mΩ
Min. insulation resistance1000MΩ
Dielectric strength1000VAC (1 minuto)
Operating temperature5 ~ 125°C
Insulator materialPBT + 30% of fiber of glass (UL94V-0)
Contact and terminal materialTin-plated phosphor bronze
Force of insertion (per contact)350g max.
Force of extraction (per contact)80g min.
