Terminal for SC Cable

CÓD: SCTF1

Description

2.50 mm wire-to-wire connector terminal for cable-to-cable connection, ensuring a secure and reliable connection. Available in female and male housing versions, with or without ears, from 2 to 12 ways. Supports up to 3A and 250 VAC/VDC, meeting various electronic and industrial applications.

  • Wire-to-wire connector terminal with 2.50 mm pitch
  • Compatible with 28 to 22 AWG cables, from 2 to 12 contacts
  • Female and male housing versions (with or without ears)
  • Capacity of up to 3A and 250 VAC/VDC

Select the options below

General specifications
Contact rating3A
Max. operating voltage250VAC or VDC
Max. initial contact resistance20mΩ
Insulation resistance1000MΩ min. (500VDC)
Dielectric strength1500VAC (1 minuto)
Operating temperature-40 ~ 105°C
Insulator materialPA66 UL94V-0
PCB connector terminal materialTin-plated brass
Material of the terminals of crimparsTin-plated brass
Applicable wire gauge for crimp terminal28 ~ 22 AWG (0.08mm² ~ 0.30mm²)

Compare to lines

Terminal for SC Cable Terminal for SC Cable see details
SC Connector Cable-to-Cable 2.50mm SC Connector Cable-to-Cable 2.50mm see details
Description
2.50 mm wire-to-wire connector terminal for cable-to-cable connection, ensuring a secure and reliable connection. Available in female and male housing versions, with or without ears, from 2 to 12 ways. Supports up to 3A and 250 VAC/VDC, meeting various electronic and industrial applications.


Wire-to-wire connector terminal with 2.50 mm pitch

Compatible with 28 to 22 AWG cables, from 2 to 12 co…
The SC series wire-to-wire connector is designed to join cables securely and reliably. Available in male and female versions, it adapts to different mounting configurations. With a capacity of up to 3A and 250V, it ensures electrical stability in low-power applications.


Available in 2 to 12 way versions

Maximum current of 3A and voltage up to 250V

Female or male (option with ear)

Supports 28…
